JA-5M36 Accelerometer

Quartz Servo Accelerometers

JA-5M36

The 150℃ JA-5M36 series accelerometers are a field proven, cost effective solution that can be used for the majority of oil and gas drilling operations. The JA-5M36 has been developed to meet the harsh requirements of downhole applications operated in low/mid temperature range. JAE is recognized as one of the leading suppliers of downhole accelerometers used in oil and gas field applications.

Downloads

Features

  • 150 °C operating temperature
  • Shock and vibration resistant
  • Ultimate reliability

Applications

Designed for extreme downhole applications including :
  • Directional Drilling
  • MWD/LWD
  • Wireline

Technical data

Environmental
Operating temperature -40℃ to +150℃
Shock (Survival) 1,500G
Electrical
Input voltage ±12 to 18V(DC)
Input current (Quiescent) 4.5 mA max.
Performance
Range ±4.0G
Resolution 1μG max.
Scale factor (Nominal@25℃) 3.0mA/G
Bias (Nominal@25℃) ±10.0mG
Bias temperature coefficient ±100μG/℃ Max.
Frequency response 500Hz Min.
Functional
Self-test Current / Voltage
Mechanical
Diameter Φ25.4mm
Height 18.8mm
Weight 50 grams max.
Note
Exportation

Accelerometers must only be exported in accordance with all relevant regulations.

Technical information provided including specifications, drawings and schematics are for reference only.
Information provided is subject to change without prior notice.
Please contact your local sales representative with any questions before ordering.
